Com base na disponibilidade de componentes, a Bianchi reserva-se o direito de efetuar alterações nas especificações sem aviso prévio.
Frame
Disc Brake Specification: Flat Mount 140/160 Bottom Braket Standard: PressFit 86.5 X diam.41 Rear Axle: thru12 OLD (Over-Locknut-Dimension): 142 mm Front Derailleur: Brazed-on Type Rear Derailleur: SRAM UDH Hanger type Max Chainring Compatibility: 46T-52T
Fork
Bianchi Impulso Integrated Fork Disc Brake Specification: Flat Mount 140/160 Front Axle: thru12 OLD (Over-Locknut-Dimension): 100 mm Tire Clearance: ETRTO 622-42mm Steer tube Diameter: 1 1/8"" Material: Carbon Fiber Composite
Headset
Bianchi Custom Acros ICR (Internal Cable Rounting)
Shifters
Shimano GRX 820 ST-RX820
Rear Derailleur
Shimano GRX 820 RD-RX820 Maximum Cassette Sprocket 36T
Front Derailleur
Shimano GRX 820 FD-RX820
Crankset
Shimano GRX 820 FC-RX820 48-31T Crank Length: 170mm-XS(47)-SM(51), 172.5mm-MD(55)-LG(58), 175mm-XL(61)
Bottom Bracket
Shimano SM-BB72-41B, press fit
Chain
Shimano CN-M7100
Cassette
Shimano CS-HG710-12 speed, 11-36T Driver body Interface: HG11
Brakes
Shimano Hydraulic Brake, BR-RX820
Rotor
Shimano SM-RT70 IceTech Hub Interface: Centerlock Rotor Diameter: 160 mm (front&Rear)
Wheels
Velomann Terbium clincher and tubeless ready Rim Diameter: 700C Material: Carbon Rim Height: 30 mm Inner Width Channel: 25 mm
Tire
Pirelli Cinturato™ GRAVEL H Classic, 40-622 tan sidewall
Stem
Velomann AICR Alloy Rise: -2° Steerer Diameter: 1-1/8"" (28.6mm) HB interface Diameter: 1-1/4"" (31.8mm) Stem Lengths: 80mm - XS(47), 90mm - SM(51), 100mm-MD(55), 110mm-LG(58),120m -XL(61)
Handlebar
Velomann Gravel ICR Alloy Flare: 16° Drop: 130mm Reach 70mm Interface Diameter: 1 1/4"" (31.8mm) HandleBar Widths: 400 - SX(47) SM(51), 420 - MD(55) LG(58), 440 -XL(61)
Grips / Extensions
La Spirale Ribbon cork
Seatpost
Bianchi Custom D-Shape Offset: 20mm Back Seatpost lengths: 300mm-SX(47), 350mm- SM(51) MD(55), 380mm-LG(58) XL(61) Material: Epoxy - HM-HS Carbon Fiber Composite
Saddle
Velomann MITORA 149 Hyper, cover: hexagon, padding: foam, shell: nylon carbon, open shell, carbon rails, lenght: 250mm, width: 149mm, weight: 190g ± 2
| A | B1 | C | D | E | F | G | G1 | H | I | X | Y | WB |
| 480 | 510 | 425 | 53 | 100 | 590 | 75.5° | 70.5° | 45 | 400 | 378 | 510 | 1009 |
| 500 | 525 | 425 | 58 | 115 | 600 | 75° | 70.5° | 45 | 400 | 383 | 529 | 1018 |
| 520 | 535 | 425 | 60 | 125 | 601 | 74.5° | 71° | 45 | 400 | 385 | 542 | 1019 |
| 540 | 545 | 425 | 60 | 135 | 602 | 74° | 71.5° | 45 | 400 | 386 | 554 | 1020 |
| 560 | 560 | 425 | 62 | 145 | 606 | 73.5° | 72° | 45 | 400 | 391 | 569 | 1024 |
| 580 | 575 | 425 | 62 | 160 | 611 | 73° | 72.5° | 45 | 400 | 396 | 583 | 1028 |
